Transverse thin corrugated sheets forming machine
Short Description:
Basic Info
Tile Type:Glazed Steel
Certification:CE, ISO
Condition:New
Customized:Customized
Usage:Roof, Floor
Transmission Method:Hydraulic Pressure
Thickness Range:0.14-0.3mm/0.16-0.4mm
Control System:PLC
Delievery Time:45 Days
Using:Roofing Sheets
Additional Info
Packaging:NUDE
Productivity:200 sets/year
Brand:YY
Transportation:Ocean
Place of Origin:Hebei China
Supply Ability:200 sets/year
Certificate:CE/ISO9001
HS Code:84552210
Port:Tianjin Xingang
Product Description
Transverse Thin Corrugated Sheet Forming Machine
Transverse Thin Corrugated Sheet Forming Machine for 0.13mm-0.45mm thin plate, Speed:9-12piece/min, High capacity, Low cost, Good discount, Short delivery.
machine technical parameter:
| 1.machine type | Barrel corrugating type |
| 2.material | steel/Aluminum |
| 3.working speed | 9-12piece/min |
| 4.sheet thickness | 0.13-0.45mm |
| 5.pinch | 75mm |
| 6.guider for sheet input | welded steel structure with stopper for setting width |
| 7.corrugating roll | barrel length 4500 mm |
| 8.pinch adjust roll | barrel length 4500 mm |
| 9.screw | adjusted by manual |
| 10.guider for output products | welded steel plate |
| 11.Up&down device for corrugating and pitch adjusting rolls | |
Transverse thin corrugated sheets forming machine
Thickness range:0.14-0.3mm/0.16-0.4mm.Accumulated thickness not exceed 0.6mm each time
Width range:≤1000mm
Regular formed length:2480mm/3050mm/3660mm/3900mm/4300mm(8 inch/10 inch/12 inch/12.7 inch/14 inch)
Forming speed:9-12m/min
Capacity:2-4T/hour
Looking for ideal Transverse Corrugated Sheets Forming Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Corrugated Sheets Forming Machine are quality guaranteed. We are China Origin Factory of Thin Corrugated Sheets Forming Machine. If you have any question, please feel free to contact us.
