Square tube mill welding machine

Short Description:


Product Detail

FAQ

Product Tags

Basic Info

Model No.:WW01-YY

Warranty:12 Months

Delivery Time:30 Days

After Service:Engineers Available To Service Machinery Overseas

Voltage:380V/3Phase/50Hz Or At Your Request

Cutting Mode:Hydraulic

Material Of Cutting Blade:Cr12

Control System:PLC

Speed:60-70m/min

Daily Production:6000 Tubes

Additional Info

Packaging:NUDE

Productivity:200 sets/year

Brand:YY

Transportation:Ocean,Land

Place of Origin:Hebei

Supply Ability:200 sets/year

Certificate:CE/ISO9001

HS Code:84552210

Port:Tianjin,Shanghai,Qingdao

Product Description



Square tube mill welding machine

Our Solid state hf Welded Pipe&Tube Line with the latest technology,meet high efficiency output ,easily operated and stable running performance,also the complete Tube Mill Line meet a high level automation. This high Solid state hf welding for Square tube mill with excellent design, selected high precision durable roller under strictly quenching , high performance cutting saw, complete machine body with heat treatment, accurate fabrication, precise assembly. The Solid state hf welding for Square tube mill performance has reached the international welded tube standard. This tube mill series outer diameter range can be from Φ7mm to Φ 50.8mm and wall thickness of 0.2~2.0mm,all these size tubes are produced with large output, best quality and high precision.Our customized machines are also can be used for different processed material and meet nearly all applications.



SpecificationofHighSquaretubemillweldingmachine
Model TubeO.D.(mm) WallThickness(mm) Speed(m/min) H.F.power(Kw) Mainmotor(Kw)
YY-12 φ7-16 0.2-0.5 30-100 60 15
YY-16 φ8-25 0.3-1.0 30-90 60 22
YY-25 φ8-30 0.4-1.3 30-90 100 37
YY-28 φ10-38 0.5-1.5 30-80 100 45
YY-32 φ13-50.8 0.6-2.0 20-90 100 75

steel pipe welding line for www.yingyee.cn002steel pipe welding line for www.yingyee.cn006steel pipe welding line for www.yingyee.cn009steel pipe welding line for www.yingyee.cn013

steel pipe welding line for www.yingyee.cn011steel pipe welding line for www.yingyee.cn008

Company information:

YINGYEE MACHINERY AND TECHNOLOGY SERVICE CO.,LTD

YINGYEE is the manufacturer specialized in various cold forming machineries and automatic production lines. We have a wonderful team with highly technology and excellent sales, which offer professional products and related service. We paid attention to quantity and after service, got great feedback and honor formal the clients. We have a great team for after service. We have sent several patch after service team to oversea to finish the products installation and adjustment. Our products were sold to more than 20 countries already. Also included US and Germany. Main product :

  • Roof roll forming machine
  • Roller Shutter Door Roll Forming Machine
  • C and Z purlin roll forming machine
  • Downpipe Roll Forming Machine
  • Light Keel Roll Forming Machine
  • Shearing Machine
  • Hydraulic decoiler
  • Bending machine
  • Slitting machine





FAQ:

Training and Installation :
1. We offer installation service local in paid, reasonable charge.

2. QT test is welcome and professional.

3. manual and using guide is optional if no visiting and no installation.


Certification and after service:

1. Match the technology standard, ISO producing certification

2. CE certification

3. 12 months warranty since the delivery. Board.


Our advantage:

1. Short delivery period

2. Effective communication

3. Interface customized.

Looking for ideal Automatic Tube Mill Line Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Automatic Welding Machine are quality guaranteed. We are China Origin Factory of Square Tube Mill Line. If you have any question, please feel free to contact us.
