Nut and bolt large span roll forming machine with bending machine

Short Description:

  • :
  • Product Detail


    Product Tags

    1 2 3 4 5 6 7 8

    The machine include :manual decoiler—punching—-forming—cut—Curving

    1. Features

    1.1 Rollers are made of good white steel processed with polishing.

    1.2 We needn’t to adjust the gaps between rollers, and can feed 0.6-1.5mm color steel sheets.

    1.3 The finished colored will be very large span, high corrugation, high tension strength.

    2. Main technical data of YY-680:

    1. Punching  part Size: 2900 mm x 1400 mm x 1300 mm

    Straight panel part size : 10000 mm x 1400 mm x 1600 mm

    Bending panel part size : 1600mmx1300mmx2500mm

    Oil pump part  size: 1200mmx1200mmx1400mm

    2. Total weight: About 15000KG

    3. Controlling System: PLC (Siemens)

    4. Punch motor Power: 4kw

    5. Forming Power: 7.5kw

    6. Bending Power: 7.5kw

    7. Cutting Power: 3.0kw

    8. Oil pump motor power:7.5kw

    9. Material of rollers: 45#steel, quenched HRC 58-62

    10. Material of roller shafts: 45#steel  75mm shafts diameter

    11. Material of cutting blade: Cr12Mov steel

    12. Step of rollers: 16 steps

    13. Feeding Width: 1000mm.

    14. Effective Width: 680mm as drawing

    15. Thickness of the coil: 0.6-1.6mm

    16. The depth of the groove: according drawings

    17. max span:42 m

    18.Operating factor of the panel: 64%
