EPS sandwich roof panel production line machine

Short Description:


Product Detail

FAQ

Product Tags

Basic Info

Model No.:yingyee010

Control System:PLC

Warranty:12 Months

Delivery Time:30 Days

Type:Roof Sheet Roll Forming Machine

Cutting Mode:Hydraulic

Material:Color Coated Steel, Galvanized Steel, Aluminum St

Way Of Driven:Chain Transmission

Voltage:As Customer’s Request

After Service:Engineers Available To Service Machinery Overseas

Forming Speed:4-6m/min

Additional Info

Packaging:NUDE

Productivity:200 sets/year

Brand:YY

Transportation:Ocean,Land,Air

Place of Origin:Hebei

Supply Ability:200 sets/year

Certificate:CE/ISO9001

HS Code:84552210

Port:Tianjin,Qingdao,Shenzhen

Product Description

EPS sandwich roof panel production line

EPS(Expanded polystyrene), well known as Styrofoam, is a good thermal insulation with waterproofing. Also, it can be recycled. However, the biggest selling point is a low price. Our EPS sandwich roof panel production line machine is a fully automation equipment system to produce various shapes of sandwich panels continuously and efficiently using EPS as a core material.

  • Beautiful appearance, low noise, high efficiency
  • Easy to install, light weight, high efficient
  • Heat insulation, insulation

Technical parameters:

Panel width 950, 970,1150mm
Panel thickness 50-200mm
Raw material Galvanized coils, Pre-painted coils, Aluminum coils
Material thickness range 0.3-0.7mm
width 1000mm, 1250mm
yield strength 235Mpa
Max coil weight 5000kgs
working speed 0-5m/min (adjustable)
Total length about 35m
Control mode PLC
Total power about 30kw
Electricty condition 380v/3phase/50hz (or depend on custmers requirement)

Working process:

Working process

Pictures of machine:

EPS sandwich roof panel production line

EPS sandwich roof panel production line

EPS sandwich roof panel production line

EPS sandwich roof panel production line

EPS sandwich roof panel production line

EPS sandwich roof panel production line

EPS sandwich roof panel production line

EPS sandwich roof panel production line

Company information:

YINGYEE MACHINERY AND TECHNOLOGY SERVICE CO.,LTD

YINGYEE is the manufacturer specialized in various cold forming machineries and automatic production lines. We have a wonderful team with highly technology and excellent sales, which offer professional products and related service. We paid attention to quantity and after service, got great feedback and honor formal the clients. We have a great team for after service. We have sent several patch after service team to oversea to finish the products installation and adjustment. Our products were sold to more than 20 countries already. Also included US and Germany. Main product :

  • Roof roll forming machine
  • Roller Shutter Door Roll Forming Machine
  • C and Z purlin roll forming machine
  • Downpipe Roll Forming Machine
  • Light Keel Roll Forming Machine
  • Shearing Machine
  • Hydraulic decoiler
  • Bending machine
  • Slitting machine



FAQ:

Training and Installation :
1. We offer installation service local in paid, reasonable charge.
2. QT test is welcome and professional.
3. manual and using guide is optional if no visiting and no installation.


Certification and after service:

1. Match the technology standard, ISO producing certification
2. CE certification
3. 12 months warranty since the delivery. Board.


Our advantage:
1. Short delivery period.
2. Effective communication
3. Interface customized.

Looking for ideal EPS Sandwich Panel Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Factory Price EPS Sandwich Production Line are quality guaranteed. We are China Origin Factory of High Efficient EPS Sandwich Line. If you have any question, please feel free to contact us.
