Slitting Line
Short Description:
Slitting line for metal multiple size and materials. This conventional production line can do galvanized, hot-rolled, stainless steel slitting with a thickness of 0.3mm-3mm and a maximum width of 1500. The minimum width can be divided into 50mm. It can be made thicker and needs special customization.
Specification
|
item
|
value
|
|
Condition
|
New
|
|
Applicable Industries
|
Hotels, Building Material Shops
|
|
Weight (KG)
|
50000
|
|
Showroom Location
|
None
|
|
Video outgoing-inspection
|
Provided
|
|
Machinery Test Report
|
Provided
|
|
Marketing Type
|
Hot Product 2023
|
|
Warranty of core components
|
1 Year
|
|
Core Components
|
PLC, motor
|
|
Place of Origin
|
China
|
|
Hebei
|
|
|
Warranty
|
1 Year
|
|
total power
|
260kw
|
|
thickness
|
0.3-2.0mm
|
|
width
|
500-1250mm
|
|
maximum coil weight
|
10000kg
|
|
cutting motor
|
DC45KW
|
Product details description
Total power:260kw
Total weight:Approx. 15tons
Dimension:Approx .(L*W*H) 22m*2m*2m
Speed:Line speed:0.3-1.0mm、max150m/min，2.0mm,120m/min
