Hot New Products Roof Tile Roll Forming Machine - Auto Metal Pipe Cutting Machine – Yingyee
Short Description:
Hot New Products Roof Tile Roll Forming Machine - Auto Metal Pipe Cutting Machine – Yingyee Detail:
Basic Info
Model No.:YY–MPC—001
Control System:PLC
Pipe Material:METAL TYPE
Feeder Type:Servo Motor Type
Oil Working Pressure:10-50KG
Cutting Type:Sawing Cutting System
Additional Info
Packaging:NAKED
Productivity:500 SETS/YEAR
Brand:YINGYEE
Transportation:Ocean
Place of Origin:CHINA
Supply Ability:500 SETS/YEAR
Certificate:ISO9001
Port:SHANGHAI
Product Description
OUR MACHINE FEATURES
1. Automatic PLC control .easy operating.
2. One machine can cut different round pipe or square pipe with different size.
3.Vertical slide feeding , strong structure , concentrate on processing of cutting chip, automatic lubrication, blade cooling , oil cooling.
4.The machine has three sets of clamping device, the pressure size were adjustable, effectively solve the material when the clamping is not strong or deformation of the problem.
5.The machine adopts servo drive feed, greatly improve the sawing accuracy.
6.The system have no material sutdown,fault deteciton and display function, easy maintenance ,maintenance.
7.The machine has a function of cutting out a variety of lengths.
TECHNICAL SPECICATION
| main specifications | 350 FA-A | 350FA-B | 425FA-A | 425FA-B | |
| Blade drive motor | 3.0/4.0kw | 3.0/4.0kw | 3.0/4.0kw | 3.0/4.0kw | |
| Blade rotational speed | 60/120RPM | 60/120RPM | 60/120RPM | 60/120RPM | |
| Feed stroke | 1500mm/time | 1500mm/time | 1500mm/time | 1500mm/time | |
| Servo motor power | 1000w | 1000w | 1000w | 1000w | |
| Pull tail strok | 150mm | 150mm | 150mm | 150mm | |
| Clamp type | up and down | left and right | up and down | left and right | |
| Cooling pump motor | 90w | 90w | 90w | 90w | |
| Hydraulic pump motor | 2.2kw | 2.2kw | 2.2kw | 2.2kw | |
| Oil working pressure | 10-50kg | 10-50kg | 10-50kg | 10-50kg | |
| Dimension | 3500*1100*1700 | 3500*1100*1700 | 3500*1100*1700 | 3500*1100*1700 | |
| Weight | 1350kg | 1350kg | 1350kg | 1350kg |
MACHINE PICTURE
Looking for ideal Metal Pipe Cutting Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Automatic Tube Cutting Machine are quality guaranteed. We are China Origin Factory of Automatic Pipe Cutting Machine. If you have any question, please feel free to contact us.
Product Categories : Auto Metal Pipe Cutting Machine
Product detail pictures:
